Spécifications
- Manufacturier : Bobcat
- Modèle : Small Articulated Loaders L23
- Type : Chargeurs
- Horsepower : 24.8 hp
- Rated Operating Capacity Straight (iso) : 1,395 lb
- Rated Operating Capacity Art. (iso) : 1,159 lb
- Operating Weight : 3790 lb
- Auxiliary Std Flow : 12.1 gal/min
- Width (over Tires) : 43.2 in
- Emissions Tier (epa) : Tier 4
- Engine Cooling : Liquid
- Engine Fuel : Diesel
- Horsepower : 24.8 hp
- Turbocharged Engine : No
- Rated Operating Capacity Straight (iso) : 1,395 lb
- Rated Operating Capacity Art. (iso) : 1,159 lb
- Roc With Counterweight Option Straight : 1815 lb
- Roc With Counterweight Option Art. : 1471 lb
- Tipping Load Straight : 2789 lb
- Tipping Load Art. : 2317 lb
- Operating Weight : 3790 lb
- Travel Speed : 8.2 mph
- Fuel Tank : 9.6 gal
- System Relief @ Quick Couplers : 2,900 psi
- Auxiliary Std Flow : 12.1 gal/min
- Drive Type : Hydrostatic Pump Driving 4 Independent Wheel Motors
- Length : 122.4 in
- Length Without Attachment : 93.2 in
- Length With Standard Bucket : 122.4 in
- Width (over Tires) : 43.2 in
- Width (with Bucket) : 44 in
- Height With Operator Cab : 78.1 in
- Height To Bucket Hinge Pin Ext : 85.4 in
- Height To Bucket Hinge Pin Ret : 85.4 in
- Max Reach : 16.8 in
- Turning Radius Inside : 77.2 in
- Turning Radius Outside : 100.9 in
- Wheelbase : 47.2 in
- Articulation Angle : 43°
- Dump Angle @ Maximum Height : 40°
- Ground Clearance : 5.5 in
- Rollback Angle : 32°
- Tire Size : 23x8.5-12
- Wheel Tread : 34.4 in
- Air Conditioning : Not Applicable
- Adjustable Seat : Standard
- Backup Alarm : Standard
- Bics System (interlock) : Standard
- Cab Enclosure : Optional
- Cab Heater : Optional
- Operating Lights : Optional
- Rear Window : Optional
- Lift-arm Support : Standard
- Two Speed Travel : Not Applicable
- Deluxe Instrumentation : Not Applicable
- Hydraulic Bucket Positioning : Standard
- Auxiliary Hydraulics : Standard
- Spark Arrestor Muffler : Standard
- Bob-tach Attachment System : Standard
- Horn : Standard
- Front And Rear Work Lights : Standard
- Rotating Flashing Beacon : Optional
- Turn Signals : Optional
- Tires-ply Rating : 10
- Heavy-duty Float Tires : Optional
- Cup Holder : Standard
- Grab Handles : N/a
